Rated Power: 360KW/480KW/600KW/720KW
Design Standard: GB/T18487-2023
Double Charge Gun
Single Gun Max Output Current: 250A
EV Charger Size: 800*1850*800mm(W*H*D)
Screen Size: 7 Inch Touch Screen
Networking method: Ethernet/4G
Charging mode: Automatic full / by time / by power / by amount
Activation mode: Swipe IC card/WeChat scan code/VIN/Password
Protection function: Short circuit/over current/over temperature/leakage/under voltage
Input Voltage: AC380V ±20%
Input Frequency: 50Hz+10%
Cable: 5 Meters
Output voltage range: DC200-1000V
Output voltage error: ≤±0.5%
Output current error: ≤±1%
Voltage regulation precision: ≤±0.5%
Accuracy of current stabilisation: ≤±1
Harmonic content: ≤5%
Power factor: ≥0.99
Maximum efficiency: ≥95%
Electricity metering: Grade 1, in line with GB standards
Noise: Grade Ⅱ
Protection grade: IP54
Cooling method: Air-cooled
Operating Temperature: -20℃~+50
Storage temperature: -40℃~+70℃
Installation mode: Floor
